Instructions
n Suitable machine:all kinds of trimming saw .
n Cutting materials:wood,pine,oak.
D(mm) | B(mm) | b(mm) | d(mm) | Z | α | T-type | Positioning hole |
300 | 3.2 | 2.2 | 30 | 48 | 15 | ZY | FT01 |
300 | 3.2 | 2.2 | 30 | 60 | 15 | ZY | FT01 |
305 | 4 | 3 | 25.4 | 48 | 15 | ZY | |
305 | 4 | 3 | 30 | 48 | 15 | ZY | |
305 | 4 | 3 | 50.8 | 60 | 15 | ZY | |
350 | 5 | 3.6 | 50.8 | 70 | 15 | ZY | 2/15/130 |
350 | 5 | 3.6 | 50.8 | 70 | 15 | ZY | 2/15/130 6/8.5/75 6/8.5/160 |
400 | 5 | 3.6 | 50.8 | 70 | 15 | ZY | 2/15/130 |
450 | 5 | 3.8 | 50.8 | 70 | 15 | ZY | 2/150/130 |
Notes:according to customer need to customize non-standard saw blade
