Instructions
Uitable for:precision cutting .
n Suitable machine:audio processing equipment and automatic,manual 45° angle cutting machine.
n Cutting materials:double veneer particleboard,MDF,plywood.
D(mm) | B(mm) | b(mm) | d(mm) | Z | α | T-type | Positioning hole |
230 | 3.2 | 2.2 | 25.4 | 60 | 15 | XZPXY | FT04 |
250 | 3.2 | 2.2 | 25.4 | 60 | 15 | XZPXY | FT04 |
250 | 3.2 | 2.2 | 25.4 | 80 | 15 | XZPXY | FT04 |
280 | 3.2 | 2.2 | 25.4 | 90 | 15 | XZPXY | FT04 |
305 | 3.0 | 2.2 | 25.4 | 120 | 15 | XZPXY | |
305 | 3.0 | 2.2 | 30 | 120 | 15 | XZPXY | |
355 | 3.5 | 2.8 | 25.4 | 120 | 15 | XZPXY | |
355 | 3.5 | 2.8 | 30 | 120 | 15 | XZPXY |
Notes:according to customer need to customize non-standard saw blade
